UsetheLLDPInterfaceSummarypagetoviewtheLLDPparametersconfiguredoneachphy sicalportonthe

system.

TodisplaytheLLDPInterfaceSummarypage,clickLAN>Monitoring>LLDPStatus > InterfaceSummary inthe

navigationtree.

Figure161:LLDPInterfaceSummary

•Toupdatethepagewiththelatestdata,clickRefresh.

ble142:LLDPInterfaceSummaryFields

Field Description

Interface DisplaysalltheportsonwhichLLDP‐802.1ABcanbeconfigured.

LinkStatus Displayswhetherthelinkstatusoftheportsisupordown.

Transmit DisplaystheLLDP‐802.1ABtransmitmodeoftheinterface.

Receive DisplaystheLLDP‐802.1ABreceivemodeoftheinterface.

Notify DisplaystheLLDP‐802.1ABnotificationmodeofthein

terface.

OptionalTLV(s) ShowstheLLDP‐802.1ABoptionaltype‐lengthvalues(TLV)thatareincluded.

IfnoTVLsaresent,theentryisblank.Thefieldcancontainoneormoreofthe

followingTVLs.

•SystemName

•SystemCapabilities

•SystemDescription

•PortDescription.

TransmitManagement

Information

ShowswhetherthemanagementaddressistransmittedintheLLDPfr

ames.
