ViewingAssociatedClientStatistics

AwirelessclientcanroamamongAPswithoutinterruptioninWLANservice.TheDWS‐4000Seriesswitch

tracksthetraffictheclientsendsandreceivesduringtheentirewirelesssessionwhiletheclientroamsamong

APsthattheswitchmanages.Theswitchstoresstatisticsaboutclienttrafficwhileitisassociatedwithasin

gle

APaswellasthroughouttheroamingsession.

ThestatisticsontheWLAN>Monitoring>Client>AssociatedClients>Statistics>AssociationSummary

displaystheAssociatedClientStatisticspage.Thispageshowsinformationaboutthetr afficawirelessclient

receivesandtransmitswhileitisassociatedwithasingl

eAP.

Figure335:AssociatedClientAssociationSummaryStatistics

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

Table301:AssociatedClientAssociationSummaryStatistics

Field Description

MACAddress TheEthernetaddressoftheclientstation.

PacketsReceived Packetsreceivedfromtheclientstation.

BytesReceived Bytesreceivedfromtheclientstation.

PacketsTransmitted Packetstransmittedtotheclientstation.

BytesTransmitted Bytestransmittedtotheclientstation.
