ViewingDetailsAboutAPAuthenticationFailures

Toviewadditionaldata(beaconinformation)foranAPintheauthenticationfailurelist,clicktheMACaddress

oftheAP.

Figure318:APAuthenticationFailureDetails

ThefollowingtabledescribesthefieldsonthedetailedAccessPointAuthenticationFailureStatuspage.

Table285:AccessPointAuthenticationFailureDetails

Field Description

MACAddress TheEthernetaddressoftheAP.

IPAddress ThenetworkIPaddressoftheAP.

LastFailureType Indicatesthelasttypeoffailurethatoccurred,whichcanbeoneofthe

following:

•LocalAuthentication

•NoDatabaseEntry

•NotManaged

•RADIUSAuthentication

•RADIUSChallenged

•RADIUSUnreachable

• InvalidRADIUSResponse

• InvalidProfileID

•ProfileMismatch‐HardwareTy

VendorID VendoroftheAPsoftware.

ProtocolVersion IndicatestheprotocolversionsupportedbythesoftwareontheAP.

SoftwareVersion IndicatestheversionofsoftwareontheAP.

HardwareType HardwareplatformfortheAP.

ReportingSwitch ShowswhethertheswitchthatreportedtheAP authenticationfailureis

thelocalswitchorapeers

witch.

SwitchMACAddress ShowstheIPaddressoftheswitchintheclusterthatreportedtheAP

authenticationfailure.

SwitchIPAddress ShowstheMACaddressoftheswitchintheclusterthatreportedtheAP

authenticationfailure.
