D-Link DWS-4026 [321/741] Configuring a secondary vrrp address

VirtualRouterRedundancyProtocol(VRRP)

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page321

D‐LinkUWSUserManual

CommandButtons

•ClickSubmittoapplythenewconfigurationandcausethechangetotakeeffect.Thesechangeswillnot

beretainedacrossapowercycleunlessaSaveconfigurationisperformed.

•ClickSecondaryIPAddresstoproceedtotheSecondaryIPAddressconfigurationpage.

•ClickDeletetodeletetheselectedVirtualRouter.Not

ethattheroutercannotbedeletedifthereare

secondaryaddre ssesconfigured.

•ClickTrackInterfacetoproceedtotheVRRPTrackInterfaceconfigurationpage.

•ClickTrackRoutetoproceedtotheVRRPTrackRouteconfigurationpage.

ConfiguringaSecondaryVRRPAddress

ToconfigureasecondaryVRRPaddress,firstconfigureoneIPaddress(theprimaryaddress)fortheVR.Then,

youcanaddmultiplesecondaryaddressestothatinterface.

•ClickSubmittoapplythenewconfigurationandcausethechangetotakeeffect.Thesechangeswillnot

beretainedacrossapowercycleunlessaSa

veconfigurationisperformed.

•ClickDeletetodeletetheselectedsecondaryIPaddress.

•ClickCancel toreturntotheVirtualRouterConfigurationpage.

ConfiguredPriority EnterthepriorityvaluetobeusedbytheVRRProuterintheelectionforthe

mastervirtualrouter.IftheVirtualIPAddressisthesameasthein

terfaceIP

Address,theprioritygetssetto255nomatterwhatyouenter.Ifyouentera

priorityof255whentheVirtualandinterfaceIPAddressesarenotthesame,

theprioritygetssettothedefaultvalueof100.

Priority TheoperationalpriorityoftheVRRPro

uter.Thisisrelativetotheconfigured

priority.Theoperationalprioritydependsupontheconfiguredpriority,and

theprioritydecrementsconfiguredthroughthetrackingprocess.

AdvertisementInterval(secs) Enterthetime,inseconds,betweenthetransmissionofadvertisement

packetsbythisvirtualrouter.Enteranumberbetween1and255.Thedefault

alueis1second.

InterfaceIPAddress IndicatestheIPAddressassociatedwiththeselectedinterface.

IPAddress EntertheIPAddressassociatedwiththeVirtualRouter.Thedefaultis0.0.0.0,

whichyoumustchangepriortoclickingCreate.

AuthenticationType SelectthetypeofAuthenticationfortheVirtualRouterfromthedropdown

menu.Th

edefaultisNone.Thechoicesare:

• 0‐None:Noauthenticationisperformed.

• 1‐Simple:Authenticationisperformedusingatextpassword.

AuthenticationData Ifyouselectedsimpleauthentication,enterthepa ssword.

Status Selectactiveorinactivefromthedropdownmenutostartorstopthe

operationoftheVirtualRouter.Thedef

aultisinactive.

Table191:VirtualRouterConfigurationFields(Cont.)

Field Description
