VLANPortSummary

UsetheVLANPortSummarypagetoviewVLANconfigurationinformationforalltheportsonthesystem.

ToaccesstheVLANPortSummarypage,clickLAN>Monitoring >VLANSummary>VLANPortSummaryin

thenavigationmenu.

Figure99:VLANPortSummary

•ClickRefreshtoreloadthepageandviewthemos

tcurrentinformation.

Table83:VLANPortSummaryFields

Field Description

Slot/Port Identifiesthephysicalinterfaceassociatedwiththerestofthedataintherow.

PortVLANIDConfigured IdentifiestheVLANIDassignedtountaggedorpriority‐taggedframesreceived

onthisport.Thefactorydefaultis1.

PortVLANIDCurrent DisplaystheactualVLANIDinusefortheport.Iftheportwasacquir

edby

anothermodule,theactualvaluemaydiffer fromtheconfiguredVLANID.For

example,iftheportisamemberofaportchannelandtheportchannelhasa

differentportVLANIDsettingthantheconfiguredvalue,thenthetwomay

differ.

AcceptableFrameTy

pes Indicateshowtheporthandlesuntaggedandprioritytaggedframes.

• VLANOnly:Theportdiscardsanyuntaggedorprioritytaggedframesit

receives.

• AdmitAll:Untaggedandprioritytaggedframesreceivedontheportare

acceptedandassignedthevalueofthePortVLANIDforthisport.

IngressFiltering Show

showtheporthandlestaggedframes.

• Enable:Ataggedframeisdiscardedifthisportisnotamemberofthe

VLANidentifiedbytheVLANIDinthetag.

• Disable:Alltaggedframesareaccepted,whichisthefactorydefault.

PortPriority Identifiesthedefault802.1ppriorityassignedtoun

taggedpacketsarrivingat

theport.
