MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page503

D‐LinkUWSUserManual

ViewingDetailedAssociatedClientAssociationStatistics

ThestatisticsontheWLAN>Monitoring>Client>AssociatedClients>Statistics>AssociationDetailtab

displaystheAssociatedClientStatisticspage.Thispageshowsinformationaboutthetrafficawirelessclient

receivesandtransmitswhileitisassociatedwithasingleAP.Usethemenuabovethetabletovie

wdetails

aboutanassociatedclient.EachclientisidentifiedbyitsMACaddress.

Figure337:AssociatedClientAssociationDetailStatistics

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

Table303:AssociatedClientAssociationDetailStatistics

Field Description

PacketsReceived Totalpacketsreceivedfromtheclientstation.

BytesReceived Totalbytesreceivedfromtheclientstation.

PacketsTransmitted Totalpacketstransmittedtotheclientstation.

BytesTransmitted Totalbytestransmittedtotheclientstation.

PacketsReceiveDropped Numberofpack etsreceivedfromtheclientstationthatweredropped.

BytesReceiveDropped Numberofbytesre

ceivedfromtheclientstationthatweredropped.

PacketsTransmitDropped Numberofpacketstransmittedtotheclientsta tionthatweredropped.

BytesTransmitDropped Numberofbytestransmittedtotheclientstationthatweredropped.

FragmentsReceived Totalfragmentedpacketsreceivedfromtheclientstation.

FragmentsTransmitted Totalfragmentedpacketstransmittedtotheclientstat

ion.

TransmitRetries Numberoftimestransmitstoclientstationsucceededafteroneor

moreretries.

TransmitRetriesFailed Numberoftimestransmitstoclientstationfailedafteroneormore

retries.

DuplicatesReceived Totalduplicatepacketsreceivedfromtheclientstation.
