ViewingRRMNeighbors

TheRRMNeighborsSummarypageshowsneighborinformationforeachVAP.Thistableisvisibleonlyfrom

theClusterController.TheClusterControllerbuildstheneighborsummarytablefromRFScanreports,from

thelistofmanagedAPsinthecluster,andfromtheinformationavailableintheprofileconfigurationdatabase.

Useth

edrop‐downmenutoviewRRMneighborsforaspecificAP(identifiedbyMACaddress)ortoviewRRM

neighborsforallAPs.

Figure351:RRMNeighbors

ThefollowingtabledescribesthefieldsontheRRMNeighborsSummarypage.

CommandButtons

Thepageincludesthefollowingbutton:

• DeleteAll—Removeallen

triesfromthelist.

• Refresh—Updatesthepagewiththelatestinformation.

Table317:RRMNeighborsSummary

Field Description

APMACAddress TheMACaddressofthemanagedAP.

VAPMACAddress TheVAPonthemanagedAPtowhichtheneighborsapply.

NeighborMACAddress TheMACaddressofthedetectedneighborVAP .

RSSI Thesignalstrengthwithwhichthisneighborisdetected

SSID NetworknameonwhichtheVAPandtheneighborar

eoperating.

Channel Channelonwhichtheneighborisoperating.

Age NumberofsecondssincetheneighborAPwasdetectedandreportedviatheRF‐Scan

report.
