MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page498

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

ViewingAssociatedClientSSIDStatus

EachmanagedAPcanhaveupto16differentnetworksthateachhaveauniqueSSID.Althoughseveralwireless

clientsmightbeconnectedtothesamephysicalAP,theymightnotconnectbyusingthesameSSID.TheWLAN

>Monitoring>Client>AssociatedClients>SSIDStatuspageliststheSSIDsofthenetwork

sthateachwireless

clientassociatedwithamanagedAPhasusedforWLANaccess.

TodisconnectaclientfromanAP,selecttheboxnexttotheSSID,andthenclickDisassociate.

Figure332:SSIDAssociatedClientStatus

CommandButtons

Thepageincludesthefollowingbuttons:

• Disassociate—

DisassociatestheclientfromthemanagedAP.

• Refresh—Updatesthepagewiththelatestinformation.

SupportRRMBeaconPassive

Measurement

Indicateswhethertheclientsupportspassivescancapability.

RRMChannelLoadMeasurement Indicateswhethertheclientsupportschannelloadmeasurement

Table298:SSIDAssociatedClientStatus

Field Description

SSID Indicatesthenetworkonwhichtheclientisconnected.

MACAddress TheEthernetaddressoftheclientstation.

Table297:AssociatedClientRRMStatus(Cont.)

Field Description
