D-Link DWS-4026 [578/741] Detailed ap provisioning status

APManagement

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page578

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbuttons:

• Delete—RemovetheselectedAPfromtheAPprovisioninglist.

• DeleteAll—RemoveallAPsfromtheAPprovisioninglist.

• Provision—InitiateprovisioningfortheselectedAP.YoucanprovisionanAPonlyfromthecluster

controller.AftertheAPisprovisioned,itshouldbecomema

nagedbytheswitchwiththeconfigured

PrimaryIPAddressandappearintheAPprovisioningdatabaseasamanagedAP.

• Refresh—Updatesthepagewiththelatestinformation.

DetailedAPProvisioningStatus

UsetheAPProvisioningStatus(detail)pagetoviewdetailedprovisioninginformationaboutanAPandto

specifytheIPaddressoftheprimaryorbackupswitchthatprovidesprovisioninginformationfortheAP.

SelecttheMACaddressoftheAPfromthedrop‐downmenutoviewprovisioninginformationaboutthatAP

Status StatusofthemostrecentlyissuedAPprovisioningcommand,which

hasoneofthefollowingvalues:

•NotStarted—ProvisioninghasnotbeendoneforthisAP.

• Success—Provisioningfinishedsuccessfullyforthisswitch.TheAP

ProvisioningStatustableshouldreflectthelatestprovisioning

configuration.

•InProgress—ProvisioningisexecutingforthisAP.

•InvalidSwitchIPAddr

ess—EitherprimaryorbackupswitchIP

addressisnotintheclusterorthemutualauthenticationmodeis

enabledandtheprimaryswitchIPaddressisnotspecified.

• ProvisioningRejected—APisnotmanagedandisconfigurednotto

acceptprovisioningdatainunmanagedmode.

•TimedOut—Thelastprovisioningrequesttimedout.

Age Amoun

toftimesincetheAPlastsentanupdate.

Note:TheAPProvisioningDetailpagedisplaysdataonlywhentheswitchisconfiguredastheCluster

Controller.

Table344:APProvisioningSummaryStatus(Cont.)

Field Description
