LLDP‐MEDInterfaceSummary

ThispagelistseachswitchinterfaceanditsLLDPconfigurationstatus.Todisplaythispage,clickLAN>

Monitoring>LLDPStatus> LLDP‐MED>InterfaceSummaryinthenavigationtree.

Figure169:LLDP‐MEDInterfaceSummary

•ClickRefreshtoupdatethepagewiththelatestinformationfromtherouter.

Table150:LL

DP‐MEDInterfaceSummaryFields

Field Description

Interface SpecifiesalltheportsonwhichLLDP‐MEDcanbeconfigured.

LinkStatus SpecifiesthelinkstatusoftheportsasUp/Down.

MEDStatus Specifiesthetransmitand/orreceiveLLDP‐MEDmodeisenabledordisabled

onthisinterface.

OperationalStatus SpecifieswhethertheinterfacewilltransmitTLVs.

NotificationStatus SpecifiestheLLDP ‐MEDtop

ologynotificationmodeoftheinterface.

TransmitTLVs SpecifiestheLLDP ‐MEDtransmitTLV(s)thatareincluded.
