MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page458

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbutton:

• DeleteAll—ManuallyclearallAPsfromtheAllAccessPointsstatuspageexceptManagedAccessPoints.

• Manage—ConfigureanAuthenticationFailedAPtobemanagedbytheswitchthenexttimeitis

discovered.SelectthecheckboxnexttotheMACa

ddressoftheAPbeforeyouclickManageYouwillbe

presentedwiththeValidAccessPointConfigurationpage.YoucanthenconfiguretheAPandclickSubmit

tosavetheAPinthelocalValidAPdatabase.IfyouuseaRADIUSserverforAPvalidation,youmustadd

theMACad

dressoftheAPtotheAPdatabaseontheRADIUSserver.

• Acknowledge—IdentifyanAPasanAcknowledgedRogue.SelectthecheckboxnexttotheMACaddress

oftheAPbeforeyouclickAcknowledge.TheswitchaddstheAPtotheValidAPdatabaseasan

Acknow

ledgedRogue.

• Refresh—Updatesthepagewiththelatestinformation.

ManagedAPStatus

FromtheWLAN>Monitoring>AccessPoint>ManagedAPStatuspage,youcanaccessavarietyof

informationabouteachAPthattheswitchmanages.ThepagesyouaccessfromtheStatustabprovide

configurationandassociationinformationaboutmanagedAPsandtheirneighbors.Thepagesyouaccessfrom

theSt

atisticstabdisplayinformationaboutthenumberofpacketsandbytestransmittedandreceivedon

variousinterfaces.

Note:SomestatusvaluesforsomeAPsintheAllAccessPointslistarenotavailable.Thosearelisted

asN/A.

Note:YoucansortthelistofAPsbyanyofthecolumnheadingexceptforRadio,Channel,and

AuthenticatedClients.Forexample,tosorttheAPsbytheprofiletheyuse,clickProfile.
