RIPInterfaceSummary

UsetheRIPInterfaceSummarypagetodisplayRIPconfigurationstatusonaninterface.

Todisplaythepage,clickLAN>Monitoring>L3Status>RIP>InterfaceSummaryinthenavigationtree.

Figure198:RIPInterfaceSummary

•ClickRefreshtoupdatetheinformationonthescreen.

Table178:RIPInterfaceSummaryFi

elds

Field Description

Slot/Port Theinterface,suchastherouting‐enabledVLANonwhichRIPisenabled.

IPAddress TheIPAddressoftherouterinterface.

SendVersion SpecifiestheRIPversiontowhichRIPcontrolpacketssentfromtheinterface

conform.ThedefaultisRIP‐2.Possiblevaluesare:

• RIP‐1:RIPversion1packetsaresentusingbr

oadcast.

• RIP‐1c:RIPversion1compatibilitymode.RIPversion2formattedpackets

aretransmittedusingbroadcast.

• RIP‐2:RIPversion2packetsaresentusingmulticast.

• None:RIPcontrolpacketsarenottransmitted.

ReceiveVersion SpecifieswhichRIPversioncontrolpacketsareacceptedbytheinterface.The

def

aultisBoth.Possiblevaluesare:

• RIP‐1:onlyRIPversion1formattedpacketsarereceived.

• RIP‐2:onlyRIPversion2formattedpacketsarereceived.

• Both:packetsarereceivedineitherformat.

• None:noRIPcontrolpacketsarereceived.

RIPAdminMode SpecifieswhetherRIPisEnabledorDisabledonthein

terface.

LinkState SpecifieswhethertheRIPinterfaceisupordown.
