TimeRangeEntryConfiguration

Usethispagetoconfigureperiodicandabsolutetimerangeentriesandaddthemtonamedtimeranges.

Toaccessthispage,clickLAN>Administration>TimeRange>TimeRangeEntryConfiguration.

Figure66:TimeRangeEntryConfiguration

Note:Thetimerangeentriesusethesystemtimeforthetimeperiodsinwhichtheytak eeffect.Make

sureyouconfiguretheSNTPserversettingssothattheSNTPclientontheswitchcanobtainthe

correctdateandtimefromtheserver.

Table56:TimeRangeEntryConfiguration

Field Description

TimeRangeName Selectthenameofthetimerangetowhichyouwanttoaddatimerange

entry.

TimeRangeEntry SelectCreateNewTimeRangeEntrytoaddanewentrytoatimerange.To

viewordeleteanexistingtimerangeentry,selectitsIDfromthemenu.

TimeRangeEntryID Whencr

eatinganewtimerangeentry,assignauniqueIDnumberfrom1–10.

Thisfielddoesnotappeariftheentryhasalreadybeenconfigured.

TimeRangeEntryType. Specifieswhethertheentryisperiodicorabsolute.Aperiodicentryoccursat

thesametimeeverydayorononeormor

edaysoftheweek.Anabsolute

entrydoesnotrepeat.
