CaptivePortalConfiguration

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page390

D‐LinkUWSUserManual

LocalUser

Youcanconfigureaportaltoaccommodateguestusersandauthorizedusers.Guestusersdonothaveassigned

usernamesandpasswords.Authorizedusersprovideavalidusernameandpasswordthatmustfirstbe

validatedagainstalocaldatabaseorRADIUSserver.Authorizeduserscangainnetworkaccessoncethesw

itch

confirmstheuser’scredentials.

TheLocalUserSummarypageallowsyoutoaddauthorizeduserstothelocaldatabase,whichcancontainup

to1024userentries.YoucanalsodeleteusersfromthelocaldatabasefromtheLocalUserSummarypage.

ToviewandconfigureCPusersinthelocalda

tabase,clickLAN>Security>CaptivePortal>LocalUser.

Anyusersthatar ealreadyconfiguredarelistedontheLocalUserSummarypage.

Figure268:CaptivePortalLocalUserSummary

Table226describesthefieldsontheLocalUserSummarypage.

Toaccesstheconfigurationpageforaspecificuserlis

tedonthepage,clicktheusername.

ThefollowingbuttonsareavailableatthebottomoftheLocalUsertable:

• Add:ClickAddtoaddanewusertotheLocalUserdatabase.

• Delete:SelectthecheckboxnexttotheusertoremoveandclickDelete.Selectmultiplecheckbo

xesto

deletemorethanoneuseratatime.

• DeleteAll:ClickDeleteAlltoremoveallconfiguredusersfromthelocaldatabase.

• Refresh:ClickRefreshtoupdatethepagewiththemostcurrentinformation.

Table226:LocalUserSummary

Field Description

User Identifiesthenameoftheuser.

SessionTimeout Showsthenumberofsecondsauserispermittedtoremainconnectedtothenetwork.

OncetheSessionTimeoutvalueisreached,theuserisloggedoutautomatically.Avalue

of0meansthattheuserdoesnothaveaSessionTimeoutlimit.

IdleTimeout Show

sthenumberofsecondstheusercanremainidlebeforetheswitchautomatically

logstheuserout.Avalueof0meansthattheuserwillnotbeloggedoutautomatically.
