D-Link DWS-4026 [466/741] Viewing managed access point neighbor aps

MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page466

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbuttons:

• Refresh—Updatesthepagewiththelatestinformation.

• Back—ReturnstotheManagedAPStatuspage.

ViewingManagedAccessPointNeighborAPs

DuringtheRFscan,anaccesspointcollectsandstoresbeaconinformationvisiblefromneighboringaccess

points.Accesspointscanstoretheneighborinformationforupto64neighborAPs.Iftheneighborscan

informationex ceedsthecapacity,theoldestdataintheneighborlistisoverwritten.

Usethemenuaboveth

etabletoselecttheAPwiththeNeighborAPinformationtoview.TheAPisidentified

byitsMACaddressandlocation.IftheAPhastworadios,selectaradiotoviewtheneighborAPsdetect edby

usinganRFscanonthatradio.Theradioisidentifiedbyit

snumberandconfiguredmode.Iftheradiois

disabled,theradiomodewillbedisplayedasOff.

Table273onpage466describesthefieldsyouseeontheNeighborAPspageforthemanagedaccesspoint

status.

CommandButtons

Thepageincludesthefollowingbuttons:

• DeleteAllNeighbors—Clearsallen

triesfromtheNeighborAPsandNeighborClientslist.Thisdeletesall

neighborsforallradiosonallAPs—notonlyforthecurrentlyselectedAPandradio.Thelistisrepopulated

asneighborsarediscovered.

• Refresh—Updatesthepagewiththelatestinformation.

Table273:ManagedAPNeighborStatus

Field Description

NeighborAPMAC TheEthernetMACaddressoftheneighborAPnetwork,thiscouldbeaphysicalradio

interfaceorVAPMACaddress.ForD‐LinkAPsthisisalwaysaVAPMACaddress.The

neighborAPMACaddressmaybecross‐referencedintheRFScanstatus.

SSID ServiceSetIDoftheneighb

orAPnetwork.

RSSI ReceivedSignalStrengthIndication,thisisanindicatorofthesignalstrengthrelative

totheneighborandmaygiveanideaoftheneighbor'sdistancefromthemanaged

AP.Therangeis1–100,where1istheweakestsignalstrength.

Status IndicatesthemanagedstatusoftheAP

,whetherthisisavalidAPknowntotheswitch

oraRogueonthenetwork.Thevalidvaluesare:

•Managed:TheneighborAPismanagedbythewirelesssystem.

• Standalone:TheAPismanagedinstandalonemodeandconfiguredasavalidAP

entry(localorRADIUS).

• Rogue:TheAPiscla

ssifiedasathreatbyoneofthethreatdetectionalgorithms.

• Unknown:TheAPisdetectedinthenetworkbutisnotclassifiedasathreatby

thethreatdetectionalgorithms.

Age IndicatesthetimesincethisAPwaslastreportedfromanRFscanontheradio.
