ARPTableConfiguration

UsethispagetochangetheconfigurationparametersfortheAddressResolutionProtocolTable.Youcanalso

usethisscreentodisplaythecontentsofthetable.

Todisplaythepage,clickLAN>L3Features>ARP>ARPTableConfigurationinthenavigationtree.

Figure186:ARPTableConfiguration

Table167:ARPTa

bleConfigurationFields

Field Description

AgeTime(secs) EnterthevalueyouwanttheswitchtousefortheARPentryageouttime.You

mustenteravalidinteger,whichrepresentsthenumberofsecondsittakesfor

anARPentrytoageout.Therangeforthisfieldis15to21600seconds.The

defaultvaluefo

rAgeTimeis1200seconds.

ResponseTime(secs) EnterthevalueyouwanttheswitchtousefortheARPresponsetimeout.You

mustenteravalidinteger,whichrepresentsthenumberofsecondstheswitch

waitsforaresponsetoanARPrequest.Therangeforthisfieldis1to10

sec

onds.ThedefaultvalueforResponseTimeis1second.

Retries EnteranintegerwhichspecifiesthemaximumnumberoftimesanARP

requestisretried.Therangeforthisfieldis0to10.Thedefaultvaluefor

Retriesis4.

CacheSize Enteranintegerwhichspecifiesthema

ximumnumberofentriesfortheARP

cache.Therangeforthisfieldisplatform‐dependent.Thedefaultvaluefor

CacheSizeis896.

DynamicRenew ThiscontrolswhethertheARPcomponentautomaticallyattemptstorenew

ARPEntriesoftypeDynamicwhentheyageout.ThedefaultsettingisDisable.

TotalEn

tryCount TotalnumberofentriesintheARPtable.
