ConfiguringARP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page287

D‐LinkUWSUserManual

TheARPTabledisplaysatthebottomofthepage,andcontainsthefollowingfields:

•Ifyoumakeanychangestothepage,clickSubmittoapplythechangestothesystem.

PeakTotalEntries HighestvaluereachedbyTotalEntryCount.Thiscountervalueisrestarted

whenevertheARPtableCacheSizev

alueischanged.

ActiveStaticEntries TotalnumberofactivestaticentriesintheARPtable.

ConfiguredStaticEntries TotalnumberofconfiguredstaticentriesintheARPtable.

MaximumStaticEntries Maximumnumberofstaticentriesthatcanbedefined.

RemovefromTable AllowsyoutoremovecertainentriesfromtheARPTable.Thechoic

eslisted

specifythetypeofARPEntrytobedeleted:

•AllDynamicEntries

•AllDynamicandGatewayEntries

•SpecificDynamicGatewayEntry

•SpecificStaticEntry

RemoveIPAddress ThisfieldappearsonlyifyouselectSpecificDynamic/GatewayEntryorSpecific

StaticEntryintheRemovefromTablemenu.Thisfieldallowsyoutoen

terthe

IPAddressagainsttheentrythatistoberemovedfromtheARPTable.

Table168:ARPTableFields

Field Description

IPAddress TheIPaddressofadeviceonasubnetattachedtooneoftheswitch'sroutinginterfaces.

MACAddress TheunicastMACaddressforthedevice.Theformatissixtwo‐digithexadecimalnumbers

separatedbycolons,forexample00:06:29:32:81:40.

Slot/Port TheroutinginterfaceassociatedwiththeARPentry.

Type ThetypeoftheARPen

try.

Age AgesincetheentrywaslastrefreshedintheARPTable.Theformatishh:mm:ss

Table167:ARPTableConfigurationFields(Cont.)

Field Description
