ConfiguringRIP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page306

D‐LinkUWSUserManual

ThesourceIPaddressiscomparedtothedestinationIPaddressoftheroute.ThesourceIPnetmaskinthe

accesslistruleistreatedasawildcardmask,indicatingwhichbitsinthesourceIPaddressmustmatchthe

destinationaddressoftheroute.(Notethata1inthema

skindicatesaDon’tCareinthecorrespondingaddress

bit.)

WhenanaccesslistruleincludesadestinationIPaddressandnetmask(anextendedaccesslist),the

destinationIPaddressiscomparedtothenetworkmaskofthedestinationoftheroute.Thedestination

netmaskintheaccesslistservesasawi

ldcardmask,indicatingwhichbitsintheroute’ sdestinationmaskar e

significantforthefilteringoperation.

•Ifyoumakechangestothepage,clickSubmittoapplythechangestothesystem.

•Todeleteaconfiguredroute,clickDelete.

RIPRouteRedistri butionSummary

UsetheRIPRouteRedistributionSummarypagetodisplayRouteRedistributionconfigurations.

Todisplaythepage,clickLAN>Monitoring>L3Status>RIP>RouteRedistributionSummaryinthe

navigationmenu.

Figure200:RIPRouteRedistri butionSummary

•ClickRefreshtoupdatetheinformationonthescreen.

Table180:RIPRouteRedistributionSum

maryFields

Field Description

Source Theprotocolusedtoobtaintheroute.

Metric TheMetricofredistributedroutesforthegivensourceroute.Displays

Unconfiguredwhennotconfigured.

DistributeListTheAccessListthatfilterstheroutestoberedistributedbytheDestination

Protocol.IftheDistributeListisnotconfigured,thefieldisblank.
