ConfiguringIGMPSnooping

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page215

D‐LinkUWSUserManual

MulticastRouterVLANConfiguration

UsetheIGMPSnoopingMulticastRouterVLANConfigurationpagetoconfiguremulticastroutersettingsfor

VLANsonaninterface.

ToaccesstheIGMPSnoopingMulticastRouterVLANConfigurationpage,clickLAN>L2Features >IGMP

Snooping>MulticastRouterVLANConfigurationinthenavigationtree.

Figure126:MulticastRouterVLANConfiguration

•Ifyo

uenableordisablemulticastrouterconfigurationforVLANsonaninterface,clickSubmittoapplythe

newsettingstotheswitch.

Table108:MulticastRouterVLANConfigurationFields

Field Description

Slot/Port SelectthephysicalorLAGinterfacetodisplay.

VLANID EntertheVLANIDtoconfigureasenabledordisabledformulticastrouting.

MulticastRouter SelectEnableorDisablefromthedrop‐downmenutochangethemulticast

routermodeoftheVLANassociatedwiththisinterface.
