TrapLog

UsetheTrapLogpagetoviewtheentriesinthetraplog.ForinformationabouthowtocopythefiletoaTFTP

server,see“UploadFileFromSwitch(TFTP)”onpage171.

ToaccesstheTrapLogpage,clickLAN>Monitoring>Log>TrapLoginthena

vigationmenu.

Figure52:TrapLog

•ClickClearLogtoclearallentriesinthelog.Subsequentdisplaysofthelogwillonlyshownewlogentries.

Table42:TrapLogFields

Field Description

NumberofTrapsSinceLast

Reset

Thenumberoftrapsgeneratedsincethetraplogentrieswerelastcleared.

TrapLogCapacity Themaximumnumberoftrapsstoredinthelog.Ifthenumberoftraps

exceedsthecapacity,theentrieswilloverwritetheoldestentries.

NumberofTrapsSinceLog

LastViewed

Thenumb

eroftrapsthathaveoccurredsincethetrapswerelastdisplayed.

Displayingthetrapsbyanymethod(terminalinterfacedisplay,Webdisplay,

uploadfilefromswitch,etc.)willcausethiscountertobeclearedto0.

Log Thesequencenumberofthistrap.

SystemUpTime Thetimeatwhichthistr

apoccurred,expressedindays,hours,minutesand

secondssincethelastrebootoftheswitch.

Trap Displaystheinformationidentifyingthetrap.
