MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page452

D‐LinkUWSUserManual

APImageCapability

Theswitchisabletoupdatesoftwareontheaccesspointsthatitmanages.ToupdatetheAPwiththecorrect

software,theUWScanstoreuptothreeAPsoftwareimagestosupportdifferentAPhardwaretypes.Thispage

displaystheimageID‐to‐hardwaretypemapping.

Figure310:ImageTable

ble263:APImageCapability

Field Description

ImageTypeID ShowstheIDnumberassignedtotheimage.

ImageTypeDescription Providesabasicdescriptionoftheimage.
