Configured(Static)Routes

UsetheConfiguredRoutespagetocreateanddisplaystaticroutes.

Todisplaythepage,clickLAN>L3Features>Router>ConfiguredRoutesinthenavigationtree.

Figure205:ConfiguredRoutes

AddingaStaticRoute

1. OpentheConfiguredRoutespage.

2. ClickAddRoute.

TheRouterRouteEntryCreatepagedisplays.Thefieldsavailableonthepagevarybasedontheroute

type.

3. NexttoRouteType,selectDefaultroute,StaticorStaticRejectfromthemenu.

• Default:EnterthedefaultgatewayaddressintheNextHo

pIPAddressfieldandthetheroute

preferencevalueinthePreferencefield.

• Static:EntervaluesforNetworkAddress,SubnetMask,NextHopIPAddress,andPreference.

• StaticReject:Packetstothesedestinationswillbedropped.

Table185:ConfiguredRoutesFields

Field Description

NetworkAddress TheIProuteprefixforthedestination.

SubnetMask Alsoreferredtoasthesubnet/networkmask,thisindicatestheportionofthe

IPinterfaceaddressthatidentifiestheattachednetwork.

NextHopIP Thenexthoprouteraddresstousewhenforwardingtraffictothedestination.

NextHopSlot/Port Theoutgoinginterfacetousewhenf

orwardingtraffictothedestination.For

staticrejectroutesitwouldbeNull0.

Note:Theroutewillnottak eeffectuntilaroutinginterfacebelongingtothe

samesubnetasthenexthopIPiscreatedandactivated,andthisfieldwill

displaythenexthopslot/portasUnresolved.

Preference Thepr

eferencesconfiguredfortheaddedroutes.
