ConfiguringSpanningTreeProtocol

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page238

D‐LinkUWSUserManual

ConfiguringSpanningTreeProtocol

TheSpanningTreeProtocol(STP)providesatreetopologyforanyarrangementofbridges.STPalsoprovide s

onepathbetweenendstationsonanetwork,eliminatingloops.Spanningtreeversionssupportedinclude

CommonSTP,MultipleSTP,andRapidSTP.

ClassicSTPprovidesasinglepathbetweenendstations,avoidingandeliminatingloops.Fo

rinformationon

configuringCommonSTP,see“CSTPortConfiguration/Status”onpage244.

MultipleSpanningTreeProtocol(MSTP)supportsmultipleinstancesofSpanningTreetoefficientlychannel

VLANtrafficoverdifferentinterfaces.EachinstanceoftheSpanningTreebehavesinthemannerspecifiedin

IEEE802.1w,RapidSpanningTree(RSTP),withsligh

tmodificationsintheworkingbutnottheendeffect(chief

amongtheeffects,istherapidtransitioningoftheportto‘Forwarding ’ ).ThedifferencebetweentheRSTPand

thetraditionalSTP(IEEE802.1D)istheabilitytoconfigureandrecognizefullduplexconnectivityandports

whichareconnectedtoends

tations,resultinginrapidtransitioningoftheportto‘Forwarding’stateandthe

suppressionofTopologyChangeNotification.Thesefeaturesarerepresentedbytheparameters‘pointtopoint’

and‘edgeport’ .MSTPiscompatibletobothRSTPandSTP.ItbehavesappropriatelytoSTPandRSTPbridges.A

MSTPbridgecanbeconf

iguredtobehaveentirelyasaRSTPbridgeoraSTPbridge.

SwitchConfiguration/Status

TheSpanningTreeSwitchConfiguration/StatuspagecontainsfieldsforenablingSTPontheswitch.

TodisplaytheSpanningTreeSwitchConfiguration/Statuspage,clickLAN>L2Features > SpanningTree >

SwitchConfiguration/Statusinthenavigationtree.

Figure149:SpanningTreeSwitchConfiguration/Status

Note:Fortwobridgestobeinthesameregion,theforceversionshouldbe802.1Sandtheir

configurationname,digestkey ,andrevisionlevelshouldmatch.Formoreinformationaboutregions

andtheireff ectonnetworktopology,ref ertotheIEEE802.1Qstandard.
