ConfiguringSpanningTreeProtocol

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page239

D‐LinkUWSUserManual

•Ifyoumakeanyconfigurationchanges,clickSubmittoapplythenewsettingstotheswitch.

•ClickRefreshtoupdatetheinformationonthescreenwiththemostcurrentdata.

Table131:SpanningTreeSwitchConfiguration/StatusFields

Field Description

SpanningTreeAdminMode EnablesordisablesSTPontheswitch.

ForceProtocolVersion SpecifiestheForceProtocolVersionparameterfortheswitch:

• IEEE802.1D:SpanningTreeProtocol(STP)

• IEEE802.1w:RapidSpanningTreeProtocol(RSTP)

• IEEE802.1s:MultipleSpanningTreeProtocol(MSTP)

ConfigurationName Nameusedtoidentifytheconfigurationcurrentlybeingus

ed.Itmaybeupto

32alphanumericcharacters.

ConfigurationRevisionLevel Numberusedtoidentifytheconfigurationcurrentlybeingused.Thevalues

allowedarebetween0and65535.Thedefaultvalueis0.

ConfigurationDigestKey Numberusedtoidentifytheconfigurationcurrentlybeingused.Thedigestkey

isgeneratedbasedontheas

sociationofVLANstodifferentinstances.To

ensurethedigestkeyissameontwodifferentswitches,themapping ofVLAN‐

to‐instancemustbethesame.

MSTID TableconsistingoftheMSTinstances(includingtheCST)andthe

correspondingVLANIDsassociatedwitheachofthem.

VID Thistablecon

sistsoftheVLANidentifier(VID)andthecorrespondingfiltering

identifier(FID)associatedwitheachVID.

FID TableconsistingoftheFIDsandthecorrespondingVLANIDsassociatedwith

eachofthem.
