MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page450

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

ViewingtheAPHardwareCapabilityList

TheswitchcansupportAPsthathavedifferenthardwarecapabilities,suchasthesupportednumberofradios,

thesupportedIEEE802.11modes,andthesoftwareimagerequiredbytheAP.FromtheAPHardware

Capabilitytab,youcanaccesssummaryinformationabouttheAPHardwaresupport,theradiosandIEEE

modessupport

edbythehardware,andthesoftwareimagesthatareavailabl efordownloadtotheAPs.

Figure308:APHardwareCapabilityInformation

Configuration Indicateswhichportionsofconfigurationwerelastreceivedfromapeerswitch,

whichcanbeoneormoreofthefollowing:

•Global

•Discovery

• Channel/Power

•APDatabase

•APProfiles

•KnownClient

•C

aptivePortal

•RADIUSClient

•QoSACL

•QoSDiffServ

Iftheswitchhasnotreceivedanyconfigurationforanotherswitch,thevalueisNone.

Timestamp Indicatesthelasttimethisswitchreceivedanyconfigurationdatafromapeerswitch.

Table260:PeerSwitchConfiguration(Cont.)

Field Description
