RouterDiscoveryStatus

UsetheRouterDiscoveryStatuspagetodisplayRouterDiscoverydataforeachport.

Todisplaythepage,clickLAN>L3Features>RouterDiscovery>Statusinthenavigationtree.

Figure202:RouterDiscoveryStatus

Table182:RouterDiscoveryStatusFields

Field Description

Slot/Port Therouterinterfaceforwhichdataisdisplayed.

AdvertiseMode ThevaluesareEnableorDisable.EnabledenotesthatRouterDiscoveryis

enabledonthatinterface.

AdvertiseAddress TheIPAddressusedtoadvertisetherouter.

MaximumAdvertise

Interval(secs)

Themaximumtime(inseconds)allowedbetweenrouteradvertisements

sentfromtheinterface.
