D-Link DWS-4026 [416/741] Port configuration

PortAccessControl

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page416

D‐LinkUWSUserManual

•Ifyouchangethemode,clickSubmittoapplythenewsettingstothesystem.

PortConfiguration

UsethePortAccessControlPortConfigurationpagetoenableandconfigureportaccesscontrolononeor

moreports.

ToaccessthePortBasedAccessControlPortConfigurationpage,clickLAN>Security>PortAccessControl>

PortConfigurationinthenavigationmenu.

Figure293:PortAccessControlPortConfiguration

DynamicVLANCreationMode Sele

ctEnabletoallowtheswitchtodynamicallycreateaRADIUS‐assigned

VLANifitdoesnotalreadyexistintheVLANdatabase.

MonitorMode SelectEnabletopermitnetworkaccessevenwhenthe802.1Xauthentication

processfails.Theswitchlogstheresultsoftheauthenticationprocessfor

diagnosticpurpose

MonitorModecanhelpyoutroubleshootDot1Xconfigurationproblems

withoutaffectingnetworkaccessforendusers.

Table246:GlobalPortAccessControlConfigurationFields(Cont.)

Field Description
