HTTPFileDownload

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page170

D‐LinkUWSUserManual

HTTPFileDownload

UsetheHTTPFileDownloadpagetodownloadfilesofvarioustypestotheswitchusinganHTTPsession(i.e.,

viayourwebbrowser).

Todisplaythispage,clickTool>HTTPFileDownloadinthenavigationmenu.

Figure88:HTTPFileDownload

•ClicktheStartFileTransferbuttontoinitiatethefiledownloa

Table74:HTTPFileDownloadFields

Field Description

FileType Specifythetypeoffileyouwanttodownload:

• Code:Choosethisoptiontoupgradetheoperationalsoftwareinflash(default).

• Configuration:Choosethisoptiontoupdatetheswitch'sconfiguration.Ifthefilehas

errorstheupdatewillbestopped.

• SSH‐1RSAKeyFile:SSH‐1Rivest‐Sh

amir‐Adleman(RSA)KeyFile

• SSH‐2RSAKeyPEMFile:SSH‐2Rivest‐Shamir‐Adleman(RSA)KeyFile(PEMEncoded)

• SSH‐2DSAKeyPEMFile:SSH‐2DigitalSignatureAlgorithm(DSA)KeyFile(PEM

Encoded)

• SSLTrustedRootCertificatePEMFile:SSLTrustedRootCertificateFile(PEMEnc

oded)

• SSLServerCertificatePEMFile:SSLServerCertificateFile(PEMEncoded)

• SSLDHWeakEncryptionParameterPEMFile:SSLDiffie‐HellmanWeakEncr yption

ParameterFile(PEMEncoded)

• SSLDHStrongEncryptionParameterPEMFile:SSLDiffie‐HellmanStrongEncryption

ParameterFile(PEMEncoded)

• CLIBanner:Choosethisoptio

ntodownloadabannerfiletobedisplayedbeforethe

Note:TodownloadSSHkeyfiles,SSHmustbeadministrativelydisabledandtherecanbe

noactiveSSHsessions.

ImageName Specifythecodeimageyouwanttodownload,eitherimage1(thedefault)orimage2.This

fieldisonlyvisiblewhenCo

deisselectedastheFileType.

SelectFile Enterthepathandfilenameorbrowseforthefileyouwanttodownload.Youmayenter

upto80characters.
