GARPPortConfiguration

UsetheGARPPortConfigurationpagetoconfigureGARPsettingsforaspecificinterface.

ToaccesstheGARPPortConfigurationpage,clickLAN>L2Features >GARP>PortConfigurationinthe

navigationtree.

Figure117:GARPPortConfiguration

Table99:GARPPortConfigurationFields

Field Description

Slot/Port SpecifiesinterfaceonwhichtoconfiguretheGARPsettings.IfyouselectAll

fromthedrop‐downmenu,thesettingsonthepageaffectallinterfaces.

PortGVRPMode ChoosetheGARPVLANRegistrationProtocoladministrativemodefortheport

byselectingenableordisablefromthepulldownmenu.Ifyouselectdisable

,

theprotocolwillnotbeactiveandtheJoinTime,LeaveTimeandLeaveAll

Timewillhavenoeffect.Thefactorydefaultisdisable.

PortGMRPMode ChoosetheGARPMulticastRegistrationProtocoladministrativemodeforthe

portbyselectingenableordisablefromthepulldownmenu.Ifyouselect

disable,th

eprotocolwillnotbeactive,andJoinTime,LeaveTimeandLeave

AllTimehavenoeffect.Thefactorydefaultisdisable.

GARPTimers

GARPJoinTimer(centisecs) SpecifythetimebetweenthetransmissionofGARPPDUsregistering(orre‐

registering)membershipforaVLANormulticastgroupincentiseconds.Enter

anumberbetween10and100(0.1to1.0seconds).Thefactorydefaultis20

centiseconds(0.2seconds).Aninstanceofthistimerex

istsforeachGARP

participantforeachport.
