CreatingPortChannels(Trunking)

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page206

D‐LinkUWSUserManual

•Ifyoumakeanychangestothispage,clickSubmittoapplythechangestothesystem.

•Toremoveaportchannel,selectitfromthePortChannelNamedrop‐downmenuandclickDelete.All

portsthatweremembersofthisPortChannelareremovedfromthePortChannelandin

cludedinthe

defaultVLAN.ThisfieldwillnotappearwhenanewPortChannelisbeingcreated.

PortChannelStatus

UsethePortChannelStatuspagetogrouponeormorefullduplexEthernetlinkstobeaggregatedtogetherto

formaport‐channel,whichisalsoknownasalinkaggregationgroup(LAG).Theswitchcantreattheport‐

channelasifitwereasinglelink.

ToaccessthePortChannelSt

atuspage,clickLAN>Monitoring>Trunking>Statusinthenavigationtree.

Figure119:PortChannelStatus

Participation Selecteachport’smembershipstatusforthePortChannelyouareconfiguring.

Therecanbeamaximumof8portsassignedtoaPortChannel.

• Include:Theportparticipatesintheportchanne

l.

• Exclude:Theportdoesnotparticipateintheportchannel,whichisthe

default.

MembershipConflicts ShowsportsthatarealreadymembersofotherPortChannels.Aportmayonly

beamemberofonePortChannelatatime.Iftheentryisblank,theportisnot

rrentlyamemberofanyPortChannel

Table101:PortChannelStatusFields

Field Description

PortChannel IdentifiestheportchannelwiththeSlot/Portinterfacenamingconvention.

PortChannelName Identifiestheuser‐configuredtextnameoftheportchannel.

PortChannelType ThetypeofthisPortChannel,whichisoneofthefollowing:

• Static:Theportchannelisstaticallymaintained.

• Dynamic:Theportchannelisdynamicallymai

ntained.

Table100:PortChannelConfigurationFields(Cont.)

Field Description
