CreatingPortChannels(Trunking)

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page205

D‐LinkUWSUserManual

Table100:PortChannelConfigurationFields

Field Description

PortChannelName SelectCreatefromthedrop‐downmenutoconfigureanewportchannel,or

selectanexistingportchannel,identifiedbytheinterfaceandname,tomodify

itssettings.Themaximumnumberofportchannelsisplatform‐dependent.

Slot/Port Afteryoucreatetheportchannel,thisfieldidentifiesthePo

rtChannelwith

theSlot/Portinterfacenamingconvention.Thisfielddoesnotappearwhile

youinitiallyconfigureanewPortChannel.

PortChannelName EnterthenameyouwantassignedtothePortChannel.Youmayenterany

stringofupto15alphanumericcharacters.Youmustspecifyavalidnamein

dertocreatethePortChannel.

LinkTrap Specifywhetheryouwanttohaveatrapsentwhenlinkstatuschanges.The

factorydefaultisenable,whichwillcausethetraptobesent.

AdministrativeMode Selectenableordisablefromthepulldownmenu.WhenthePortChannelis

disablednotrafficwi

llflowandLACPDUswillbedropped,butthelinksthat

formthePortChannelwillnotbereleased.Thefactorydefaultisenable.

LinkStatus IndicateswhetherthelinkisUporDown.

STPMode SelecttheSpanningTreeProtocol(STP)AdministrativeModeassociatedwith

thePortChannel:

• Disable:Spanningtreeisdisable

dforthisPortChannel.

• Enable:SpanningtreeisenabledforthisPortChannel.

StaticMode Selectenableordisablefromthepulldownmenu.Thefactorydefaultis

Disable.

• Enable:Theportchannelisstaticallymaintained,whichmeansitdoesnot

transmitorprocessreceivedLAGPDUs.Thememberportsdonottr

ansmit

LAGPDUsandalltheLAGPDUsitmayreceivearedropped.Astaticport‐

channelinterfacedoesnotrequireapartnersystemtobeableto

aggregateitsmemberports.

• Disable:Theportchannelisdynamicallymaintained.Theinterface

transmitsandprocessesLAGPDUsandrequiresapartnersystem

LoadBalance Selecttheha

shingalgorithmusedtodistributethetrafficloadamong

availablephysicalportsintheLAG.Therangeofpossiblevaluesmayvarywith

thetypeofswitch.Thepossiblevaluesare:

•SourceMAC,VLAN,EtherType,andsourceport

•DestinationMAC,VLAN,EtherT ypeandsourceport

• Source/DestinationMAC,VLAN,EtherT ype,andsourceport

•S

ourceIPandSourceTCP/UDPPort

•DestinationIPandDestinationTCP /UDPPort

• Source/DestinationIPandsource/destinationTCP/UDPPort

PortChannelMembers Afteryoucreateoneormoreportchannel,thisfieldliststhemembersofthe

PortChannelinSlot/Portform.Iftherearenoportchannelsonthesystem,

thisfieldis no

tpresent.

Slot/Port Thiscolumnliststhephysicalportsavailableonthesystem.
