ConfiguringaVirtualAccessPoint

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page673

D‐LinkUWSUserManual

Configurationpage,selectEnablefromtheAdministrativeModemenu,andthenclickSubmit.

13. Tosetthe802.1Xmodeforport0/1,gototheLAN>Security>PortAccessControl>PortConfiguration

page,selectForceAuthorizedfromtheControlModefield,andthenclickSubmit.

ConfiguringaVirtualAccessPoint

Thefollowingexampleshowshowtoconfigurethedefaultvirtualaccesspoint(VAP)profileontheswitch.

AftertheswitchauthenticatesanAPitdiscoversonthenetwork,itassignsthedefaultprofiletotheAP.Inorder

fortheswitchandAPtodiscovereachother,theWLANSwitchfeaturemu

stbeenabledontheUWS,andthe

ManagedModemustbeenabledontheAP.

ThedefaultprofileinthisexamplehasthreeenabledVAPswiththefollowingsettings:

TheVoicenetworkusesthedefaultRADIUSserverconfiguredonthesystemtoauthenticateclientsandhas

theL2DistributedTunnelingModeenable

d.

TheVoicenetworkalsousesaDiffServpolicytoexpeditethevoicetraffic.Thepolicymustalreadybe

configuredinordertoassociateitwiththeVoicenetwork.Youconfigurethepolicybyusingthepagesavailable

fromtheLAN>QoS>DifferentiatedServicesfolder.Forinformationaboutc

onfiguringDiffServpolicies,see

“ConfiguringDiffer entiatedServicesforVoIP”onpage677.

1. AccesstheWLAN>Administration>BasicSetuppage,andthenclicktheSSIDtab.

Bydefault,Network1isenabledanduses“GuestNetwork”astheSSID.

2. ConfigurethefirstVAP .

a. ClickEditforNetwork1toaccesstheWi

relessNetworkConfigurationpageforthatnetwork.

b. DeletetheexistingSSIDandenterVisitorintheSSIDfield.

c. IntheVLANfield,enter10.

d. IntheRedirectfield,selecttheHTTPoption.

Table384:VAPConfigurationExampleSettings

Network(SSID) VLAN Security Redirect ClientQoS

Visitor 10 None http://www .dlink.com.tw http://www .dlink.com.tw

BandwidthRestrictions

Corporate 20 WPAPersonal None None

Voice 30 WP AEnterprise None DiffServPolicyUp

Note:WhenL2Distributedtunnelingisenabled,notethefollowingnetworkconsiderations:

•IfAPsarelocatedindifferentsubnets,theclientVLANsmustalsobeseparatedbyarouterso

thattheVLANsdonotformasinglebridgesegment.

•IftheIPaddressesoftheAPsareonthesamesubn

et,allVLANsusedbythewirelessclients

mustalsobelocatedinthesamebridgesegment.
