ConfiguringDynamicARPInspection

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page274

D‐LinkUWSUserManual

DAIARPACLRuleConfiguration

UsetheDAIARPACLRuleConfigurationpagetoaddorremoveDAIARPACLRules.

TodisplaytheDAIARPACLRuleConfigurationpage,clickLAN>L2Features > DynamicARPInspection>DAI

ARPACLRuleConfigurationinthenavigationtree.

Figure176:DynamicARPInspectionARPACLRuleCon

figuration

•ClickAddtoaddanewARPACLrule.

•ClickSubmittodeletetheentriesselectedintheRemovecolumn.

•ClickRefreshtorefreshthepagewiththemostcurrentdatafromtheswitch.

Table157:DynamicARPInspectionARPACLRuleConfiguration

Field Description

ARPACLName SelecttheARPACLforwhichinformationistobedisplayedorconfigured.

SenderIPAddress TocreateanewrulefortheselectedARPACL,enterinthisfieldtheSenderIPAddress

matchvaluefortheARPACL.

SenderMAC

Address

Tocreateanewrulefortheselect

edARPACL,enterinthisfieldtheSenderMACAddress

matchvaluefortheARPACL.

Remove UsetheRemovecolumntoselecttheparticularARPACLRulesyouwanttodelete.
