Table231describesthefieldsdisplayedontheCPGlobalStatuspage.

ViewingCPActivationandActivityStatus

TheCPActivationandActivityStatuspageprovidesinformationabouteachCPconfiguredontheswitch.

Figure273:CPActivationandActivityStatus

TheCPActivationandActivityStatuspagehasa drop‐downmenuthatcontainsallcaptiveportalsconfigured

ontheswitch.Whenyouselectacaptiveportal,theactivationandactivitystat

usforthatportaldisplays.

Table231:GlobalCaptivePortalStatus

Field Description

CPGlobalOperationalStatus ShowswhethertheCPfeatureisenabled.

CPGlobalDisableReason IndicatesthereasonfortheCPtobedisabled,whichcanbeoneofthe

following:

•None

• AdministrativelyDisabled

•NoIPv4Address

•RoutingEnabled,butnoIPv4routinginterface

SupportedLocalUsers ShowsthenumberofentriesthattheLocalUs

erdatabasesupports.

ConfiguredLocalUsers Showsthenumberofusersconfiguredinthesystem.

SystemSupportedUsers Showsthenumberofauthenticatedusersthatthesystemcansupport.

CPIPAddress Showsthecaptiveport alIPaddress

SupportedCaptivePortals Showsthenumberofsupportedcaptiveportalsinthesystem.

ConfiguredCaptivePortals Showsthenumb

erofcaptiveportalsconfiguredontheswitch.

ActiveCaptivePortals Showsthenumberofcaptiveportalinstancesthatareoperationallyenabled.

AuthenticatedUsers Showsthenumberofuserscurrentlyauthenticatedtoallcaptiveportal

instancesonthisswitch.
