APManagement

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page574

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

DebuggingtheAP

YoucanenabledebuggingonanAPtoallowTelnetaccesstotheaccesspoint.OnceyouTelnettotheAP,you

canissuecommandsfromtheCLItohelpyoutroubleshoot.

ThefieldsinTable342onpage574appearwhenyouclicktheDebuglinkforamanagedAPonth

eManaged

APAdvancedpage.

Figure376:ManagedAPDebug

Power ClickthePowerlinktoaccesstheManagedAPChannel/PowerAdjustpage.From

thatpage,youcansetanewpowerlevelfortheAP.Themanualpowerchange

overridesthepowersettingconfiguredintheAPprofileandisnotreta

inedwhenthe

APrebootsorwhentheAPprofileisreapplied.Table343onpage576describesthe

fieldsonthenewpage.

Table342:ManagedAPDebug

Field Description

MACAddress ShowstheMACaddressoftheaccesspoint.

Location Showsthelocationoftheaccesspoint,asconfiguredintheValidAPdatabase.

IPAddress ShowstheIPaddressoftheAP.

Status Showsthedebugstatus,whichcanbeoneofthefollowing:

•None:Debugginghasnotbeenenabledordisabled.

•SetR

equested:Arequesthasbeenmadetochangethedebugstatus.

•SetComplete:Debugginghasbeenenabledordisabled.

Password EntertheadminpasswordfortheAP(thedefaultisadmin).

Table341:AdvancedAPManagement(Cont.)

Field Description
