ViewingtheRRMChannelLoadHistory

TheRRMChannelLoadHistorypageshowsthelast100channelloadhistoryentries.Ifanewentryisadded

whenthelistisfullthentheoldestentryispurged.

Figure350:RRMChannelLoadHistory

ThefollowingtabledescribesthefieldsontheRRMChannelLoadHistorypage.

CommandButtons

Thepa

geincludesthefollowingbuttons:

• DeleteAll—Removeallentriesfromthelist.

• Refresh—Updatesthepagewiththelatestinformation.

Table316:RRMChannelLoadHistory

Field Description

ClientMACAddress MACAddressoftheclientthatreportedthechannelloadmeasurement.

Channel Channelonwhichtheclientmeasuredutilization.

Duration Howlongtheclientmeasuredthechannel.Thevalueisintimeunits(TUs).forwhich

tomeasurethechannel.EachTUisequalto1024

µs.

ChannelLoad MeasuredChannelLoad.Thevalueisreportedintermsofpercentageutilization.

Age Timesincethismeasurementwasreported.
