MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page461

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbuttons:

• Delete—Clearstheselectedentryfromthecurrentlist.OnlyAPswithaConfigurationStatusofFailedcan

beremovedfromthelist.

• DeleteAll—ClearsallAPswithaConfigurationStatusofFailedfromthecurrentlist.

• Refresh—Updatesthepagewiththelatestin

formation.

ViewingDetailedManagedAccessPointStatus

ToviewdetailedinformationaboutanAPthattheswitchmanages,clicktheMACaddressoftheAPfromthe

SummarypageorselecttheMACaddressoftheAPfromthedrop‐downmenuontheDetailpage.

Table269describesthefieldsyouseeontheDetailpageforthema

nagedaccesspointstatus.Thelabelatthe

topofthetableshowstheMACaddressandlocationoftheAPtowhichthevaluesonthepageapply.Toview

detailsaboutadifferentAP,selectitsMACaddressfromthedrop‐downmenu.

ClicktheResetbuttontoresetthemanag

edAP.Apop‐upmessageasksyoutoconfirmthatyouwanttoreset

theAP.Anywirelessclientsassociatedwiththeaccesspointwillbedisassociated.Torefreshthestatus

informationfortheAP,clickRefresh.

Table269:DetailedManagedAccessPointStatus

Field Description

IPAddress TheIPaddressofthemanagedAP.

IPSubnetMask ThesubnetmaskofthemanagedAP

Status ThecurrentmanagedstateoftheAP.Thepossiblevaluesare:

•Discovered:TheAPisdiscoveredandbytheswitch,butisnotyetauthenticated.

• Authenticated:TheAPhasbeenvalidatedandauthenticated(ifaut

henticationis

enabled),butitisnotconfigured.

•Managed:TheAPprofileconfigurationhasbeenappliedtotheAPandit's

operatinginmanagedmode.

• ConnectionFailed:TheDWS‐4000SeriesswitchlostcontactwiththeAP,afailed

entrywillremaininthemanagedAPdatabaseunlessyouremoveit.Notetha

ta

managedAPwilltemporarilyshowafailedstatusduringareset.

Note:WhenmanagementconnectivityislostforamanagedAP,thenbothradiosof

theAPareturneddown.AlltheclientsassociatedwiththeAPgetdisassociated.The

radiosbecomeoperationalifandwhenthatAPismanag

edagainbyaswitch.

SoftwareVersion IndicatestheversionofsoftwareontheAP,thisislearnedfromtheAPduring

discovery.
