MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page460

D‐LinkUWSUserManual

IPAddress ThenetworkIPaddressofthemanagedAP.

SoftwareVersion ThesoftwareversiontheAPiscurrentlyrunning.

Age TimesincelastcommunicationbetweentheDWS‐4000SeriesswitchandtheAP.

Status ThecurrentmanagedstateoftheAP.Thepossiblevaluesare:

•Discovered:TheAPisdiscoveredandbytheswitch,bu

tisnotyetauthenticated.

• Authenticated:TheAPhasbeenvalidatedandauthenticated(ifauthenticationis

enabled),butitisnotconfigured.

• Managed:TheAPprofileconfigurationhasbeenappliedtotheAPandit'soperating

inmanagedmode.

•Failed:TheDWS‐4000SeriesswitchlostcontactwiththeAP,afaileden

trywi ll

remaininthemanagedAPdatabaseunlessyouremoveit.NotethatamanagedAP

willtemporarilyshowafailedstatusduringareset.

Note:WhenmanagementconnectivityislostforamanagedAP,thenbothradiosofthe

APareturneddown.AlltheclientsassociatedwiththeAPgetdisa

ssociated.Theradios

becomeoperationalifandwhenthatAPismanagedagainbyaswitch.

ConfigurationStatus ThisstatusindicatesiftheAPisconfiguredsuccessfullywiththeassignedprofile.The

statusisoneofthefollowing:

•NotConfigured:TheprofilehasnotbeensenttotheAPyet,theAPma

ybe

discoveredbutnotyetauthenticated.

•InProgress:TheswitchiscurrentlysendingtheAPprofileconfigurationpackettothe

AP.

•Success:TheentireprofilehasbeensenttotheAPandtherewerenoconfiguration

errors.

• PartialSuccess:TheentireprofilehasbeensenttotheAPandther

ewere

configurationerrors(forexample,someconfigurationparameterswerenot

accepted),buttheAPisoperational.

• Failure:TheprofilehasbeensenttotheAPandtherewereconfigurationerrors,the

APisnotoperational.

Profile TheAPprofileconfigurationcurrentlyappliedtothemanagedAP.Theprofileisassigned

totheAPinthev

alidAPdatabase.

Note:OnceanAPisdiscoveredandmanagedbytheDWS‐4000Seriesswitch,ifthe

profileischangedinthevalidAPdatabase(eitherlocallyorontheRADIUSserver)the

APmustberesettoconfigurewiththenewprofile.

Radio Showsthewir

elessradiomodethateachradioontheAPisusing.

Channel Showstheoperatingchannelfortheradio.

Authenticated

Clients

Showsthenumberofwirelessclientsassociatedandauthenticatedwiththeaccesspoint

perradio.

Note:YoucansortthelistofAPsbyclickinganyofthecolumnheadings.Forexample,tosorttheAPs

bytheprofiletheyuse,clickProfile.

Table268:ManagedAccessPointStatus(Cont.)

Field Description
