CommandButtons

Thepageincludesthefollowingbuttons:

• Disassociate—DisassociatestheclientfromthemanagedAP.

• Refresh—Updatesthepagewiththelatestinformation.

ViewingAssociatedClientQoSStatus

TheWLAN>Monitoring>Client>AssociatedClients>ClientQoSpagefortheassociatedclientstatusshows

informationaboutthebandwidthrestrictionsforeachclientassociatedtoanAPmanagedbytheswitch.Use

themenuabovethetabletoselecttheMACaddressoftheclientwiththein

formationtoview.

Figure327:AssociatedClientQoSStatus

Table293onpage492describestheinformationavailableontheClientQoSpagefortheassociatedclient

status.

Table293:AssociatedClientQoSStatus

Field Description

Actual

RADIUS(Cached)

Usetheselectortodeterminethesourceoftheinformationthepagedisplays:

• SelectActualtodisplayeithertheactualstatusparametersconfiguredontheAP.

• SelectRADIUS(Cached)todisplayanyclientQoSparametersthatwereobtained

fortheclientfromaRADIUSserverwhenusing802.1Xaut

hentication.

ClientQoSOperational

Status

ShowswhetherQoSisenforcedfortheclient.

BandwidthLimitDown ShowsthemaximumrateatwhichtheclientreceivestrafficfromtheAPinbitsper

second.

Therateshowninthisfieldistheconfiguredvalueroundeddowntothenearest64

kbps,Avalueof0me

ansnobandwidthlimitingisineffectinthisdirection.

BandwidthLimitUp ShowsthemaximumrateatwhichtheclienttransmitstraffictotheAPinbitsper

second.

Therateshowninthisfieldistheconfiguredvalueroundeddowntothenearest64

kbps,Avalueof0me

ansnobandwidthlimitingisineffectinthisdirection.

AccessControlDown ShowswhichACL,ifany,isappliedtotrafficfromtheAPtotheclient.
