ManagingtheBOOTP/DHCPRelayAgent

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page278

D‐LinkUWSUserManual

BOOTP/DHCPRelayAgentStatus

UsetheBOOTP/DHCPRelayAgentStatuspagetodisplaytheBOOTP/DHCPRelayAgentconfigurationand

statusinformation.

Todisplaythepage,clickLAN>Monitoring>L3Status>BOOTP/DHCPRelayAgentStatusinthenavigation

tree.

Figure179:BOOTP/DHCPRelayAgentStatus

Table160:BOOTP/DHCPRelayAgentStatusFields

Field Description

MaximumHopCount ThemaximumnumberofHopsaclientrequestcangowithoutbeingdiscarded.

ServerIPAddress TheIPaddressoftheBOOTP/DHCPserverortheIPaddressofthenextBOOTP/DHCP

RelayAgent.

AdminMode Theadministrativemodeoftherelay.WhenyouselectEnableontheconfiguration

page,BOOTP/DHCPrequestsar

eforwardedtotheIPaddressyouenteredinthe

ServerIPaddressfield.

MinimumWaitTime

(secs)

TheMinimumtimeinseconds.Thisvalueiscomparedtothetimestampinthe

client'srequestpackets,whichshouldrepresentthetim esincetheclientwas

poweredup.Packetsareonlyforwardedwh

enthetimestampexceedstheminimum

waittime.

CircuitIDOptionMode ThisistheRelayagentoption,whichcanbeeitherEnabledorDisabled.Ifyouselect

Enable,therelayagentaddsOption82headerpacketstotheDHCPRequestpackets

befor eforwardingthemtotheser ver,andstripsthemof

fwhileforwardingthe

responsestotheclient.

RequestsReceived ThetotalnumberofBOOTP/DHCPrequestsreceivedfromallclientssincethelast

timetheswitchwasreset.

RequestsRelayed ThetotalnumberofBOOTP/DHCPrequestsforwardedtotheserversincethelast

timetheswitchwasreset.

PacketsDiscarded ThetotalnumberofBOO

TP/DHCPpacketsdiscardedbythisRelayAgentsincethe

lasttimetheswitchwasreset.
