ViewingtheDualImageStatus

TheDualImagefeatureallowstheswitchtohavetwoD‐LinkDWS‐4000Seriessoftwareimagesinthe

permanentstorage.Oneimageistheactiveimage,andthesecondimageisthebackup.Thisfeaturereduces

thesystemdown‐timeduringupgradesanddowngrades.YoucanusetheDualImageSt

atuspagetoview

informationaboutthesystemimagesonthedevice.

TodisplaytheDualImageStatuspage,clickLAN>Monitoring> DualImageStatusinthenavigationmenu.

Figure91:DualImageStatus

•ClickRefreshtodisplaythelatestinformationfromtherouter.

Table77:DualImageStatusFields

Field Description

Unit DisplaystheunitIDoftheswitch.

Image1Ver Displaystheversionoftheimage1codefile.

Image2Ver Displaystheversionoftheimage2codefile.

Current‐active Displaysthecurrentlyactiveimageonthisunit.

Next‐active Displaystheimagetobeusedonthenextrestartofthisunit.

Image1Description Displaysthede

scriptionassociatedwiththeimage1codefile.

Image2Description Displaysthedescriptionassociatedwiththeimage2codefile.
