VirtualRouterRedundancyProtocol(VRRP)

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page325

D‐LinkUWSUserManual

VRRPRouteTracking

UsetheVRRPRouteTrackingpagetoaddarouteintothetrackinglist.Toaccessthispage,clickAddfromthe

VRRPRouteTrackingpage.

Figure216:VRRPRouteTracking

•ClickSubmittosendtheupdatedconfigurationtotheswitch.Configurationchangestakeeffect

immediately.Thesechangeswillnotberetainedac

rossapowercycleunlessaSaveisperformed.

•ClickCancel toreturntotheVRRPRouteTrackingConfigurationpage.

VirtualRouterStatus

UsetheVirtualRouterStatuspagetodisplayvirtualrouterstatus.

Todisplaythepage,clickLAN>Monitoring>L3Status>VirtualRouterStatusinthenavigationtree.

Figure217:VirtualRouterStatus

Table195:VRRPRouteTrackingFields

Field Description

Interface TheInterfaceassociatedwiththeVirtualRouterID.

VirtualRouterID TheVirtualRouterIDforwhichdataistobedisplayed.

TrackRoutePfx Theprefixoftheroute.

TrackRoutePfxLen Theprefixlengthoftheroute.

PriorityDecrement Theprioritydecrementfortheroute.Thevalidrangeis1‐254.Thedefault

valueis10
