ConfiguringIGMPSnoopingQueriers

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page218

D‐LinkUWSUserManual

•IfyouconfigureanIGMPsnoopingquerier,clickSubmittoapplythenewsettingstotheswitch.

•ClickRefreshtore‐displaythepagewiththelatestinformationfromtheswitch.

IGMPSnoopingQuerierVLANConfiguration

UsethispagetoconfigureIGMPqueriersforusewithVLANsonthenetwork.

Toaccessthispage,clickLAN>L2Features >IGMPSnoopingQuerier>IGMPSnoopingQuerierVLAN

Configurationinthenavigationtree.

Figure129:IGMPSnoopingQuerierVLANConfiguration

•IfyouconfigureasnoopingquerierforaVLAN,cli

ckSubmittoapplythenewsettings.

•ClickRefreshtore‐displaythepagewiththelatestinformationfromtheswitch.

QuerierExpiryInterval Specifythetimeintervalinsecondsafterwhichthelastquerierinformationis

removed.TheQuerierExpiryIntervalmustbeavalueintherangeof60and

300

.Thedefaultvalueis60seconds.

Table111:IGMPSnoopingQuerierVLANConfigurationFields

Field Description

VLANID SpecifiesVLANIDforwhichtheIGMPSnoopingQuerieristobeenabled.

SelectNewEntrytocreateanewVLANIDforIGMPSnooping.

QuerierElectionParticipate

Mode

EnablesordisablesQuerierParticipateMode.Whenthismodeisdisabled,

uponseeinganotherquerierofsameversionintheVLAN,thesn

ooping

queriermovestonon‐querierstate.

Whenenabled,thesnoopingquerierparticipatesinquerierelection,inwhich

theleastIPaddressoperatesasthequerierinthatVLAN.Theotherquerier

movestonon‐querierstate.

SnoopingQuerierVLAN

Address

SpecifiestheSnoopingQuerierAddresstobeusedassourceIPa

ddressin

periodicIGMPqueriessentonthespecifiedVLAN.

Table110:IGMPSnoopingQuerierConfigurationFields(Cont.)

Field Description
