UnderstandingtheUserInterfaces

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page59

D‐LinkUWSUserManual

TheD‐LinkDWS‐4000SeriesswitchnavigationtreealsocontainsaLANtabforwiredfeaturesandaWLANtab

forWirelessfeatures,asthefollowingfigureshows.

Figure5:LANandWLANTabs

ConfigurationandMonitoringOptions

Thepaneldirectlyunderthegraphicandtotherightofthenavigationmenudisplaystheconfiguration

informationorstatusforthepageyouselect.Onpagesthatcontainconfigurationoptions,youcaninput

informationintofieldsorselectoptionsfromdrop‐downmenus.

EachpagecontainsaccesstotheHTML‐basedhel

pthatexplainsthefieldsandconfigurationoptionsforthe

page.Manypagesalsocontaincommandbuttons.

ThecommandbuttonsinthefollowingtableareusedthroughoutthepagesintheWebinterface:

Table2:CommonCommandButtons

Button Function

Submit ClickingtheSubmitbuttonsendstheupdatedconfigurationtotheswitch.Configuration

changestakeeffectimmediately,butchangesarenotretainedacrossapowercycleunless

yousavethemtothesystemconfigurationfile.

Note:Tosavetheconfigurationtonon‐volatilememory,usetheSaveChangesoption

fromtheAdministrationToolsmenu.

fresh ClickingtheRefreshbuttonrefreshesthepagewiththelatestinformationfromthe

router.

Logout ClickingtheLogoutbuttonendsthesession.

Caution!Submittingchangesmakesthemeffectiveduringthecurrentbootsessiononly.Youmust

saveanychangesifyouwantthemtoberetainedacrossapowercycle(reboot).Tosavechanges

acrossapowercycle,usetheSaveChangesoptionfromtheAdministrationToolsmenu.

LAN Tab WLAN Tab
