ManagingVLANs

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page182

D‐LinkUWSUserManual

•Ifyoumakeanychangestothepage,clickSubmittoapplythechangestothesystem.TodeleteaVLAN,

selecttheVLANfromtheVLANIDandNamefield,andthenclickDelete.Youcannotdeletethedefault

VLAN.

VLANStatus

UsetheVLANStatuspagetoviewinformationabouttheVLANsconfiguredonyoursystem.

ToaccesstheVLANStatuspage,clickLAN>Monitoring >VLANSummary>VLANStatusinthenavigationtree.

Figure97:VLANStatus

•ClickRefreshtodisplaythelatestinformationfromtherouter.

Tagging Selectthetaggingbehaviorfo

rthisportinthisVLAN.Thefactorydefaultis

“Untagged.”Thepossiblevaluesare:

• Tagged:allframestransmittedforthisVLANwillbetagged.

• Untagged:allframestransmittedforthisVLANwi llbeuntagged.

Table81:VLANStatusFields

Field Description

VLANID TheVLANIdentifier(VID)oftheVLAN.TherangeoftheVLANIDis1to3965.

VLANName ThenameoftheVLAN.VLANID1isalwaysnamedDefault.

VLANType TheVLANtype,whichcanbeoneofthefollowing:

• Default:(VLANID=1)‐‐alwayspresent

• Static:AVLANyo

uhaveconfigured

• Dynamic:AVLANcreatedbyGVRPregistrationthatyouhavenot

convertedtostatic,andthatGVRPmaythereforeremove

Table80:VLANConfigurationFields(Cont.)

Field Description
