ManagingVLANs

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page181

D‐LinkUWSUserManual

Figure96:VLANConfiguration

Table80:VLANConfigurationFields

Field Description

VLANIDandName YoucanusethisscreentoreconfigureanexistingVLAN,ortocreateanew

one.UsethispulldownmenutoselectoneoftheexistingVLANs,orselect

Createtoaddanewone.

VLANID‐Individual SpecifytheVLANIdentifierforthenewVLAN.(Youcanonlyen

terdatainthis

fieldwhenyouarecreatinganewVLAN.)TherangeoftheVLANIDis(1to

3965).

VLANID‐Range SpecifytherangeofVLANIdentifiersforthenewVLANstobecreated.

VLANName UsethisoptionalfieldtospecifyanamefortheVLAN.Itca

nbeupto32

alphanumericcharacterslong,includingblanks.Thedefaultisblank.VLANID

1isalwaysnamed“Default.”

VLANType ThisfieldidentifiesthetypeoftheVLANyouareconfiguring.Youcannot

changethetypeofthedefaultVLAN(VLANID=1):itisalwaystype“De

fault.”

WhenyoucreateaVLAN,usingthisscreen,itstypewillalwaysbe“Static.”A

VLANthatiscreatedbyGVRPregistrationinitiallyhasatypeof“Dynamic.”You

canusethispulldownmenutochangeitstypeto“Static.”

Slot/Port Indicateswhichportisassociatedwiththefieldsonthisline.

Status Indic

atesthecurrentvalueoftheparticipationparameterfortheport.

Participation UsethisfieldtospecifywhetheraportwillparticipateinthisVLAN.The

factorydefaultis“Autodetect.”Thepossiblevaluesare:

• Include:ThisportisalwaysamemberofthisVLAN.Thisisequivalentto

registrationfixedintheIEEE802.

1Qstandard.

• Exclude:ThisportisneveramemberofthisVLAN.Thisisequivalentto

registrationforbiddenintheIEEE802.1Qstandard.

• Autodetect:SpecifiesthatportmaybedynamicallyregisteredinthisVLAN

viaGVRP.Theportwi llnotparticipateinthisVLANunlessitreceivesa

GVR

Prequest.ThisisequivalenttoregistrationnormalintheIEEE802.1Q

standard.
