•ClickRefreshtoupdatetheinformationonthescreenwiththemostcurrentdata.

RemoteDeviceSummary

UsetheLLDPRemoteDeviceSummarypagetoviewinformationaboutallinterfacesonthedevicethatare

enabledtotransmitLLDPinformation.

TodisplaytheLLDPRemoteDeviceSummarypage,clickLAN >Monitoring>LLDPStatus> RemoteDevice

Summaryinthenavigationtree.

Figure166:LLDPRemoteDeviceSummary

•ClickRefreshtoupd

atetheinformationonthescreenwiththemostcurrentdata.

PortDescription Displaystheuser‐defineddescriptionoftheport.

SystemCapabilities

Supported

Displaysthesystemcapabilitiesoftheremotesystem.

SystemCapabilitiesEnabled Displaysthesystemcapabilitiesoftheremotesystemwhicharesupported

andenabled.

TimetoLive DisplaystheTi

metoLivevalueinsecondsofthereceivedremoteentry.

ManagementAddress Displaystheadvertisedmanagementaddressoftheremotesystem.

ManagementAddressType Displaysthetypeofthemanagementaddress.

Table147:LLDPRemoteDeviceSummaryColumns

Field Description

LocalInterface Showstheslot/portonthelocalsystemthatcanreceiveLLDPframes

advertisedbyaremotesystem.

ChassisID Identifiesthechassiscomponentassociatedwiththeremotesystem.

PortID Identifiesthephysicaladdressoftheportontheremotedevicethatsentthe

LLDPdata.

RemoteID Showstheremoteclientiden

tifierassignedtotheremotesystem.

SystemName Showsthesystemnameoftheremotedevice.Ifthesystemnameisnot

configured,thefieldisblank.
