D-Link DWS-4026 [261/741] Remote device information

ManagingLLDP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page261

D‐LinkUWSUserManual

•ClickRefreshtoupdatetheinformationonthescreenwiththemostcurrentdata.

RemoteDeviceInformation

UsetheLLDPRemoteDeviceInformationpagetoviewthedatathataspecifiedinterfacehasreceivedfrom

otherLLDP‐enabledsystems.

TodisplaytheLLDPRemoteDeviceInformationpage,clickLAN>Monitoring>LLDPStatus> RemoteDevice

Informationinthenavigationtree.

Figure165:LLDPRemoteDeviceInformation

Table145:LL

DPLocalDeviceSummaryColumns

Field Description

Interface Displaystheslot/portonwhichLLDP‐802.1ABframescanbetransmitted.

PortID Displaysthestringdescribingthesourceoftheportidentifier.

PortDescription Displaysthedescriptionoftheportassociatedwiththelocalsystem.

Table146:LLDPRemoteDeviceInformationFields

Field Description

LocalInterface Selecttheslot/portonthelocalsystemtodisplaytheLLDPinformationithas

received.

Note:IfnoLLDPdatahasbeenreceivedontheselectinterface,thena

messagestatingsodisplays.IftheselectedinterfacehasreceivedLLDP

informationfromaremotedevice,thefollowingfieldsdisplay:

RemoteID Displa

ystheremoteclientidentifierassignedtotheremotesystem.

ChassisIDSubtype IdentifiesthetypeofdatadisplayedintheChassisIDfieldontheremote

system.

ChassisID Identifiesthechassiscomponentassociatedwiththeremotesystem.

PortIDSubtype Identifiesthetypeofdatadisplayedintheremotesystem’sPortIDfield.

rtID Identifiesthephysicaladdressoftheportontheremotesystemfromwhich

thedatawassent.

SystemName Identifiesthesystemnameoftheremotesystem.

SystemDescription Displaysthedescriptionoftheselectedportassociatedwiththeremote

system.
