InterfaceConfiguration

UsetheLLDPInterfaceConfigurationpagetospecifyLLDPparametersthatareappliedtoaspecificinterface.

TodisplaytheLLDPInterfaceConfigurationpage,clickLAN>L2Features > LLDP > InterfaceConfigurationin

thenavigationtree.

Figure160:LLDPInterfaceConfiguration

•Ifyoumakeanychangestothepage,clickSubmittoapplythenewset

tingstothesystem.

Table141:LLDPInterfaceConfigurationFields

Field Description

Interface Specifiestheporttobeaff ectedbytheseparameters.

Transmit EnablesordisablesthetransmissionofLLDPprotocoldataunits(PDUs).The

defaultisdisabled.

Receive EnablesordisablestheabilityoftheporttoreceiveLLDPPDUs.Thedefaultis

disabled.

Notify Whennotificationsareenabled,LLDPinteractswiththeTrapManagerto

notif

ysubscribersofremotedatachangestatistics.Thedefaultisdisabled.

TransmitManagement

Information

Selectthecheckboxtoenablethetransmissionofmanagementaddress

instance.Clearthecheckboxtodisablemanagementinformation

transmission.Thedefaultisdisabled.

OptionalTLV(s) Selecteachcheckboxnexttothetype‐lengthvalue(TLV)in

formationto

transmit.Choicesinclude:

•SystemName. ToincludesystemnameTLVinLLDPframes.Toconfigure

theSystemName,see“SystemDescription”onpage63.

•SystemDescription.ToincludesystemdescriptionTLVinLLDPframes.

•SystemCapabilities.ToincludesystemcapabilityTLVinLLDPframes.

•PortDescription.Toincludeportde

scriptionTLVinLLDPframes.To

configurethePortDescription,see“PortDescription”onpage109
