SerialPort

TheSerialPortConfigurationpageallowsyoutochangetheswitch’sserialportsettings.Inorderforaterminal

orterminalemulatortocommunicatewiththeswitch,theserialportsettingsonbothdevicesmustbethe

same.Somesettingsontheswitchcannotbechanged.

Tovieworconfiguretheserialportse

ttingsontheswitch,clickLAN>Administration>SerialPortinthe

navigationtree.

Figure14:SerialPort

•Ifyouchangeanydata,clickSubmittoapplythechangestothesystem.Ifyouwanttheswitchtoretain

thenewvaluesacrossapowercycle,youmustperformasa

ve.

Table8:SerialPortFields

Field Description

SerialPortLoginTimeout

(minutes)

Indicateshowmanyminutesofinactivityshouldoccuronaserialport

connectionbeforetheswitchclosestheconnection.Enteranumberbetween

0and160.Thefactorydefaultis5.Entering0disablesthetimeout.

BaudRate(bps) Selectthedefaultbaudratefortheserialportc

onnectionfromthemenu.The

factorydefaultis115200.

CharacterSize(bits) Thenumberofbitsinacharacter.Thisisalways8.

FlowControl Whetherhardwareflowcontrolisenabledordisabled.Itisalwaysdisabled.

StopBits Thenumberofstopbitspercharacter.Itsisalways1.

Parity Theparitymethoduse

dontheserialport.ItisalwaysNone.
